Insulated Personnel Doors
LoTemp Insulated Personnel Doors are engineered for light to medium duty applications, catering to personnel foot traffic and light cartage. These doors offer superior energy efficiency compared to traditional wood, steel, or composite options. Crafted with durability in mind, our PD2 personnel door features metal-clad HDPE casings, a PVC profile door jamb with integrated thermal break, and USDA-approved steel or aluminum face sheets. With at least 1.75” of polyurethane insulation (R16), our doors ensure optimal temperature retention. Corrosion-resistant hardware and mechanisms guarantee long-lasting performance, while jamb-mounted compression gaskets and adjustable sweep gaskets provide a secure seal.
Wood-free design – aircraft-grade aluminum internal door panel frame
Three stainless steel butt hinges (Hager #1101)
Insulated with a minimum of 1.75” R16, foamed-in-place polyurethane foam insulation
Stainless steel lockset (Hager #3600 lever-style)
- Insulated with a minimum of 1.75” R16, foamed-in-place polyurethane foam insulation
- Wood-free design with the use of white heavy duty High-Density Polyethylene Extrusion (HDPE) structural frame for header, casings, jambs, and mirror image backframes.
- HDPE is a maintenance-free solution that provides exceptional resistance to moisture, fading, insects, splintering, and warping.
- Consistent density and zero voids eliminate bacteria, molds, and fungus growth and create a strong durable frame.
- The strength, durability, and overall appearance of HDPE mean no additional steel cladding of the frame is required.
- Variety of 24 ga. metal finishes
- .040 aluminum finish
- 1.75” thick door panel
- Perimeter jamb mount compression gasket
- Adjustable sweep gasket hardware
- Three stainless steel butt hinges (Hager #1101)
- Stainless steel lockset (Hager #3600 lever-style)
- Door closer (Hager #5200)
- Panic bar (Hager #4701)
- Vision panels (14” x 14”, 14” x 24”)
- Heated vision panels
- Kick plates
- 24 ga. Stainless steel, smooth, embossed, 304#4
- 24 ga. Sanisteel, smooth, white
- 24 ga. Galvanized, smooth, embossed, white
- 24 ga. Galvanized, smooth, mill
- .040 Aluminum, smooth, embossed, white
- .040 Aluminum, smooth, mill
- ETL Certified
- ANSI
- UL 471CAN
- CSA C22.2 No.120 Listed
A comprehensive range of options is available for all LoTemp Doors, allowing you to incorporate features tailored to your specific cold storage application.
- High Sill
- Keyed cylinder (Hinged doors only)
- Stainless Steel hardware (Hinged doors only)
- Vision panels
- Kick plates
- Meat rail ports
- Rain hoods
- Interior jambs
- Back frames
- Locking devices
- Pedestrian pass doors (Sliding doors only)
- Alternative finishes
- Ability to source hardware per specification including electronic hardware, exit devices, door closers, etc.
1-Year Warranty*
*See LoTemp Limited Warranty for full details.
